Startup Configuration: Dell™ TrueMobile™ 1150 Series AP1000 User's Guide

	Introduction
	Factory-Set Configuration

Introduction

Your TrueMobile access point comes with software. Together with this software, the access point has also been loaded with a factory-set configuration that allows for out-of-the box operation.

NOTE: The factory-set configuration is not the same as a "default" configuration. For example, when performing a "Reboot" or "Forced Reload" (described later in this book) the unit will NOT return to the "factory-set" configuration.

To connect to the access point, the TrueMobile network parameters of each wireless station should be configured to match the values as identified for the access point unit.

When powering up your access point for the first time, these values should match the values listed in the "Startup Configuration - Access Point" table.
For normal operation, these values should match the ones you identified when you configured the access point. Dell recommends that you record this information on the Access Point Configuration Record in this section.

Factory-Set Configuration

Startup Configuration - Access Point

TrueMobile Access Point Parameters
Access Point IP tab	Obtain an IP address from DHCP server	Enabled
	Default TTL	64
SNMP tab	Read Password	public
	Read/Write Password	public
	System Name	xx-xx-xx-xx-xx-xx ¹
	Trap Host IP address	0.0.0.0 ²
	Trap Host Password	public
	SNMP IP Access List	<All will be permitted>
Bridge tab	Protocols to Filter	<none>
	Static MAC address Filter	<none>
	Spanning Tree	disabled
	Storm Thresholds	disabled
Access Control tab	(Static) Access Control	<All will be permitted>
	RADIUS Server Access Control	Disabled
Link Integrity tab	Link Integrity	Disabled

¹ Ethernet MAC address of the device (printed on a small label on the processor module).

² No SNMP traps are sent with this IP address.

Table: Startup Configuration - Interface

TrueMobile Interface
TrueMobile network name		TrueMobile network¹
RF-Channel	2.4 GHz	2.462 MHz 2.484 MHz 2.422 GHz	France Japan All other countries
Closed wireless system		Disabled
Encryption		Disabled
Medium reservation		Disabled
Microwave oven robustness support		Disabled
DTIM period		1
Distance between APs		Large
Multicast rate		2 Mbit/s

¹When your network includes MS-DOS® stations using the TrueMobile DOS ODI driver, Dell recommends that you change the value to a name that consists of "UPPER CASE" characters only.
